Basic Info.
Model NO.
customized
Surface Treatment
Offset Printing
Usage
Cosmetics, Toothpaste, Food, Medicine, Chemical
Material
Aluminum
Supplier
Junsam Packaging
Raw Material
Aluminum Purity Greater Than 99.7%
Color Printing
Max 6 Colors or Paper Stickers
Cap
Cylindrical Cap, Screw, Octagonal, Cylinder
Lead Time
15 to 20 Days
Samples
Free(Stock Samples)
Packaging
Strong Corrugated Carton
Price Term
Fob, CIF, CNF etc.
Capacity
5ml/10ml/15ml/20ml/30ml/50ml/60ml/100ml/120ml
Caps Option
Screw Caps or Standup(Top-Slip)Caps,etc.
Transport Package
Sanitary Bag+Corrugated Carton
Specification
from diameter 13.5mm to 40mm
Trademark
Customized
Origin
China
HS Code
76121000
Production Capacity
300, 000PCS Per Day
Packaging & Delivery
Package Size
50.00cm * 40.00cm * 21.00cm
Package Gross Weight
2.500kg
Product Description
How much do you know about aluminum collapsible?
The aluminum collapsible tubes usually are applied with white coating on the ground, which offers good basic for printing impression.
The Metal Empty Aluminium Collapsible Tube Packaging is an ideal packaging of:
Food container ( animal food,etc)
Cosmetic products( hair colour cream, hand cream, lip balm, and other the semi-liquid material)
pharmacy ointment products ( eye ointment, personal care products like shaving cream, shoe polish etc.. )
The pure aluminum packaging is recyclable and environment-friendly.
The Aluminum Collapsible Tube is made from aluminum
slug or flake of purity 99.7%, which makes the packaging
tube recyclable and environment-friendly.
Below are some key specifications about the Aluminum Tube Packaging:
| Wide ranging diameters: | 13.5 mm, 16 mm, 19 mm, 22 mm, 25 mm, 28 mm, 30 mm, 32 mm, 35 mm, 38mm, 40mm |
| Thread/ Screw: | M7, M9, M11, M12, M15, M16 |
| Various nozzle: | membrane-sealed, open end, extended nozzle, long nozzle, nasal tips, ophthalmic tips |
| Tube shoulder type: | Polished, blank, coating, printing, pattern |
| Internal coating/lacquer: | High-quality phenolic epoxy resin. It is critical to adapt the high-quality and anti-leaking epoxy phenolic with reliable and stable performance to your tubes, and also it's key element to spray the inner coating properly, OR the coating won't protect the products from corrosion and even leads to leakage. |
| Bottom sealant: | It is optional and there are various sealants for the tubes, and it depends on customers' filling |
| Usage of aluminum tube packaging | |
| Pharmaceuticals | creams,ointments,gels for eyes,skin.etc. |
| Toiletries and cosmetics | Toothpaste,hair color/dye,shaving cream,,herbal cosmetics,hand cream, shampoos |
| Adhesives and rubber solutions | Adhesives,cyano-acrylates,rubber solutions,lubricants |
| Paints and inks | Duplication inks,colour paints.oil colours,water colours |
| Food products | Mustard,butter,cheese spread |
| Others | shoe polish etc. |
Important Note: Kindly note that the size may varies due to different fomulation of products.
| Diameter | Length(mm) | Suggested Volume |
| 13.5 | 55~65 | 5ml / 0.17oz |
| 13.5 | 62~71 | 6ml / 0.20oz |
| 13.5 | 70~80 | 7ml / 0.24oz |
| 13.5 | 78~85 | 8ml / 0.27oz |
| 16 | 60~70 | 10ml / 0.34oz |
| 16 | 72~80 | 10ml / 0.34oz |
| 16 | 100~110 | 15ml / 0.51oz |
| 19 | 57~70 | 15ml / 0.51oz |
| 19 | 77~88 | 15ml / 0.51oz |
| 19 | 96~107 | 20ml / 0.68oz |
| 19 | 115~126 | 25ml / 0.85oz |
| 22 | 95~105 | 25ml / 0.85oz |
| 22 | 108~119 | 30ml / 1.01oz |
| 22 | 122~133 | 35ml / 1.18oz |
| 25 | 89~100 | 30ml / 1.01oz |
| 25 | 101~112 | 35ml / 1.18oz |
| 25 | 140~150 | 50ml / 1.69oz |
| 28 | 140~145 | 60ml / 2.03oz |
| 30 | 120~130 | 50ml / 1.69oz |
| 30 | 170~175 | 90ml / 3.04oz |
| 30 | 175~180 | 100ml / 3.38oz |
| 32 | 165~170 | 100ml / 3.38oz |
| 32 | 175~180 | 120ml / 4.06oz |
| 35 | 165~170 | 120ml / 4.06oz |
| 38 | 130~140 | 100ml / 3.38 oz |
| 38 | 180~190 | 180ml / 6.08 oz |
| 40 | 140~150 | 200ml / 6.76 oz |
| 40 | 200~210 | 200ml / 6.76 oz |
More options for aluminum tube , please click here.
6-colors print machinery from German Mahr:
Because of the 6-colors print machinery of aluminum flexible tube and skillful technicians, we are capable of printing artwork with complicated design, which makes your packaging outstanding from the common competitors, and benefits your marketing.
Because of the 6-colors print machinery of aluminum flexible tube and skillful technicians, we are capable of printing artwork with complicated design, which makes your packaging outstanding from the common competitors, and benefits your marketing.
5-colors domestic print machinery:
We've been supplying aluminum collapsible tubes at the most competitive price with our domestic print machinery.
We've been supplying aluminum collapsible tubes at the most competitive price with our domestic print machinery.
Automatic cap twisting machinery:
The auto cap twist machine greatly expedites the lead time of aluminium empty tube, meanwhile it saves labor cost dramatically.
The auto cap twist machine greatly expedites the lead time of aluminium empty tube, meanwhile it saves labor cost dramatically.
Dust-free workshop:
The tube packaging for pharmacy products is produced in dust-free sanitary workshop specifically to ensure all the tubes are produced and packed in compliant with the regulation of pharmaceutical or medicine packaging.
The tube packaging for pharmacy products is produced in dust-free sanitary workshop specifically to ensure all the tubes are produced and packed in compliant with the regulation of pharmaceutical or medicine packaging.
Test:
Inner lacquer / lining must pass the test before releasing the shipment.
The lacquer is sprayed to the inner wall of the aluminum soft tube evenly to block chemical reaction especially between strong- ammonia hair color cream and the aluminum.
Inner lacquer / lining must pass the test before releasing the shipment.
The lacquer is sprayed to the inner wall of the aluminum soft tube evenly to block chemical reaction especially between strong- ammonia hair color cream and the aluminum.
Warehouse:
Our warehouse covers an area over 6,000 square meters, which makes it very practical to consolidate the raw materials and production and deliver the shipment accoring to the customers' request, thus save customer's storage cost.
Our warehouse covers an area over 6,000 square meters, which makes it very practical to consolidate the raw materials and production and deliver the shipment accoring to the customers' request, thus save customer's storage cost.
Regular packing vs. divider pack:
The Aluminum Collapsible Tube is flexible and it's very easy to get it dented, so packing the tubes in dividers can protect the foldable tube packaging to a great extent from getting deformed. This solution meets the requirement of the customers who have none tolerance with minor dent.
Junsam at the oversea Cosmetic Exhibitions:
Cosme Tech Show, 2019, Japan, booth # 21-7 EBS Show, 2019, Mexico, booth # D437D
1.
Q: How is your MOQ?A: Our MOQ is generally 50,000 pieces each design/art, but for the customers who have various skus, we could do 30,000 pieces as well to consolidate
2.
Q: How is your leadtime?
A: It takes generally 15 to 20 days. It could be shorter in slow season; while it could be longer in peak season.
But we always do our best to help deliver the urgent orders.
3.
Q: Can we get some samples from you? Are you going to charge us for the samples?
A: Storage samples are always free any time. But customized samples with your art printed will cost for the mold, and it takes about 7 days to deliver customized samples.
4.
Q: What is your payment term?
A: Normally 30% deposit before production and 70% balance should be paid by T/T before shipment, while it could be negotiable for the good credit old customers.
5.
Q: What is the diameter range are you capable of with the aluminum tube?
A: Our general diameter ranges from 13.5 mm to 40 mm.
6.
Q: Our company is launching several new products, and we're looking for a metal collapsible tube type. This is the first time we work on the aluminum tubes, what would be the process if we are going to orde from you?
A: We could follow the steps as:
~ We will quote you the price per your requirement about the tubes. (Basic information about dimater and length or volume, cap will be needed. If you don't know anything about the size, you could refer to the Volume chart we provided above.)
~ Free samples will be sent to you for your evaluation or testing inner lacquer stability.
~ Customized samples will be made for you given you provided the artwork.
~ After you approved the samples, we could start the cooperation procedure.
Please feel free to contact us to get more information and free samples!
