Basic Info.
Model NO.
500sqft
Treatment
Coated
Thickness
Thick Foil
Surface State
Double light Aluminum Foil
Rolling Characteristics
Rolling
Material
Pulp
Application
Food Packaging
Alloy
8011
Surface
Bright
Use
Food Take
Transport Package
Polywood Case
Specification
thickness 0.006mm
Trademark
JUN AO
Origin
China
Production Capacity
5000mt Per Month
Packaging & Delivery
Package Size
55.00cm * 33.00cm * 4.50cm
Package Gross Weight
2.000kg
Product Description
JUN AO(CHINA) LIMITED
Technical date sheet
Aluminum and aluminum alloys foil for Cold forming
- Chemical composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Rest | |
| Single | Total | |||||||||
| 8011/8021 | 0.50-0.9 | 0.6-1.0 | 0.10 | 0.20 | 0.05 | 0.05 | 0.10 | 0.08 | 0.05 | 0.15 |
- Alloy Temper Specification
| Alloy | Temper | Specification | |||
| Thickness /mm | Width /mm | I.D./mm | O.D./mm | ||
| 8011/8021 | O | 0.03-0.045 | 250-1000 | 76.2 | 300-580 |
| 152.4 | 450-750 | ||||
2. Thickness
| Thickness/mm | Tolerance | |
| 0.03-0.045 | High precision level | Ordinary level |
| ±4 | ±6 | |
3. Width
| Width/mm | Tolerance |
| ≤800 | ±1 |
| >800 | ±1.5 |
4. Core O.D.
| O.D./mm | Tolerance |
| 300-750 | ±20 |
5. Mechanical property
| Alloy | Temper | Thickness /mm | Tensile test results | |
| T.S. Rm/N/m | Elongation A100mm/% | |||
| 8011/8021 | O | |||
| >0.03-0.045 | 60-110 | 4 | ||
6.Heat sealing strength
| Composite material | |
| PVC | |
7. Pinholes
| Thickness/mm | Pinholes/ | Pore diameter(mm) |
| 0.03-0.045 | 0 | - |
8. Joint
| O.D./mm | Each volume allowed number of joint | Joint spacing/m | |
| Thickness:<=0.05mm | Thickness:>0.05mm | ||
| <=500 | <=1 | 0 | >1000 |
| >500 | <=2 | ||
9. Core I.D.
| I.D./mm | I.D. tolerance | Length tolerance |
| 76.2 | ±0.5 | ±4.0 |
| 152.4 | ±1.0 |
This standard is based on GBT 22645-2008/China national standard
