Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA

Looking for custom PCB and PCBA manufacturing? Our factory offers OEM&ODM design services for consumer electronics. Contact us today!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Company Profile
  • Exhibitions
  • Product Application
  • Certifications
  • Package & Shipment
  • FAQ
Overview

Basic Info.

Model NO.
JXpcba
Application
Medical Instruments
Mechanical Rigid
Rigid
Material
Copper-Based
Brand
Jxpcba
PCBA Material
Fr4, High Tg, Halogen-Free, High Frequency
Component Packing
Tary, Tube, Tape
Number of Layer
1-32
Minimum Line Width/Spacing
3.0mil
Surface Treatment
HASL/Immersion Gold/Immersion Silver/Immersion Tin
Certificate
ISO9001/ISO14001/CE/RoHS
PCB Solder Mask
White, Black, Yellow, Green, Red, Blue
PCB Silkscreen Color
Black, White, Yellow
Number of Layers
1-32
PCBA Testing Service
Aoi, Ict, X-ray, Flying Probe Test
Service
One-Stop Turnkey
Maximum Board Size
640mm*1100mm
Board Thickness
0.2mm~6.0mm
PCBA Packaging
Static Packaging, Shockproof Packaging, Anti-Drop
Product Application
Consumer Electronics/Home Appliances/Medical Equip
Transport Package
Air Bubble Film+Carton
Specification
custom
Trademark
JXPCBA
Origin
China
HS Code
8534009000
Production Capacity
100000

Product Description



Product Description



Specification:
PCB layers: 1-24layers
PCB materials: CEM1, CEM3, Teflon, Rogers, FR-4, High Tg FR-4, Aluminum Base, Halogen Free
PCB max. board size: 620mm*1100mm
PCB certificate: RoHS Directive-Compliant
PCB Thickness: 1.6 ±0.1mm
Out Layer Copper Thickness: 0.5-5oz
Inner Layer Copper Thickness: 0.5-4oz
PCB max. board thickness: 6.0mm
Minimum Hole Size: 0.20mm
Minimum Line Width/Space: 3/3mil
Min. S/M Pitch: 0.1mm(4mil)
Plate Thickness and Aperture Ratio : 30:1
Minimum Hole Copper: 20µm
Hole Dia. Tolerance(PTH): ±0.075mm(3mil)
Hole dia. Tolerance(NPTH): ±0.05mm (2mil)
Hole Position Deviation: ±0.05mm (2mil)
Outline Tolerance: ±0.05mm (2mil)
PCB solder mask: Black, white, yellow
PCB surface finished: HASL Leadfree,Immersion ENIG,Chem Tin,Flash Gold,OSP,Gold finger,Peelable,Immersion Silver
Legend: White
E-test: 100% AOI, X-ray, Flying probe test.
Outline: Rout and Score/V-cut
Inspection Standard: IPC-A-610CCLASSII
Certificates: UL (E503048),ISO9001/ISO14001/IATF16949
Outgoing Reports: Final Inspection, E-test, Solderability Test, Micro Section and More

PCB Assembly OEM Service
Electronic Components Material Purchasing
Bare PCB Fabrication
Cable, Wire-harness Assembly, Sheet Metal, Electrical Cabinet Assembly Service
PCB Assembly Service:  SMT, BGA, DIP
PCBA test: AOI, In-Circuit Test (ICT), Functioal Test (FCT)
Conformal Coating Service
Prototyping and Mass Production

PCBA ODM service
PCB Layout, PCBA Design According To Your Idea
PCBA Copy/Clone
Digital Circuit Design / Analog Circuit Design/ lRF Design /Embedded Software Design
Firmware and Microcode Programming Windows Application (GUI) Programming/Windows Device Driver (WDM) Programming
Embedded User Interface Design / lSystem Hardware Design
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
JX offers pcb production services from 1-32 layers Rigid, 1-8 Layers flexible, 1-16 Layer Rigid-Flex pcb. The materials include FR4, High TG, Halogen-free, High frequency (Rogers, Arlon\Taconic, Nelco, Taixing Microwave F4B, Isola) etc.,
JX offers PCB Assembly service from prototype to mass production. Components range from 0201, BGA,QFN and QFP to Through holes. AOI and X-ray are equipped to ensure the quality. SMT stencil and cable assembly services can be provided together.
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA

Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
JX offers electronic components sourcing service. Components are purchased from ST, ATMEL,  XILINX etc., for prototypes and reliable distributors for large quantities. All IC chips, transistors, crystals etc., are new and original. The quality of all components can be assured after many years experience.

Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA

Company Profile

Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA

We have equipments of over 50 SMT machines from Japan and Korea, automatic solder paste printing machines, solder paste inspection machine(SPI), 12 temperature zone reflow soldering machine, AOI detector, X-RAY detector, wave soldering machine, EM PCB dispenser, laser print machine etc., Different line configurations can meet requirements from small sample order to bulk shipment.

Our company has obtained ISO 9001 quality system certification and ISO 14001 system certification. With multi-testing procedures, our products carry out the quality system standard strictly. With end to end one-stop manufacturing solution, the company has become a benchmarking enterprise in the industry, and has been earning industry praises and good reputation from domestic and international customers depending on rigorous, techniques, good quality, fast delivery and excellent service.

Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA

Exhibitions
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA



Product Application
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA



Certifications
Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA

Package & Shipment

Consumer Electronics PCB Custom Printed Circuit Board PCBA Manufacture OEM&ODM Design PCBA
Our company is not only trying to give customers a good product but also pay attention to offering a complete and safe package. And here we prepare some personalized services for all the orders.

Common packaging:
PCB: Vacuum packaging with carton box
PCBA:ESD packaging with carton box

Shipping:
1.Confirming your shipping address is correct before delivery
2.Orders processed timely after the payment verification
3.Professional package. No worry about goods breakage.
4.Service transit time is upon different carrier, may vary particularly during holiday.
FAQ



Q1.What is needed for quotation?
A: PCB : Quantity, Gerber file and Technic requirements(material, surface finish treatment, copper thickness, board thickness )
PCBA: PCB information, BOM, (Testing documents)

Q2. What file formats do you accept for production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

Q3. Are my files safe?
A: Your files are held in complete safety and security. We protect the intellectual property for our customers in the whole process.
All documents from customers are never shared with any third parties.


Q4. MOQ?
A: There is no MOQ. We are able to handle Small as well as large volume production with flexibility.

Q5.Shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us
to quote you the shipping cost.


Q6. Do you accept process materials supplied by clients?

A Yes, we can provide component source, and we also accept component from client.





Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
